ADC Diagnostix 752M Mobile Aneroid Sphyg
$294.53 – $329.82
Questions? Speak with a Product Specialist!
The 752M offers our clock-face aneroid with a versatile mobile platform for the ultimate in portability. The traditional Adcuff variation features two-piece cuffs and bladders:
- Durable 210 denier nylon construction
- Integral flap that secures bladder and prevents bulging
- ADC’s proprietary Size Guide marking system prevents mis-cuffing
- Longer limb ranges for improved patient coverage
- Gauge hang tab (on most sizes), bladder flap, and “property of” tag
- Hook-and-loop adhesive rated to a minimum of 30,000 open/close cycles
- Three-year warranty on cuffs
The Adcuff+ model features our all-new, one-piece reusable nylon blood pressure cuffs:
- Bladderless construction from TPU-coated, 70 denier nylon that’s simple to use and easy to clean
- Surface-mounted tube ports for a more uniform fit around patient limb
Made without phthalates or natural rubber latex. Assembled, inspected, and packaged in the U.S.A from foreign components. Meets or exceeds ANSI/AAMI/ISO 81060-1.
| Aneroids BP Brand | |
|---|---|
| Configuration | Small Adult, Black, LF, Small Adult, Royal Blue, LF, 1 pc Cuff, Small Adult, Royal Blue, Adult, Black, LF, Adult, Navy, LF, 1 pc Cuff, Adult, Navy, Large Adult, Burgundy, LF, 1 pc Cuff, Large Adult, Burgundy, Large Adult, Black, LF, Thigh, Black, LF, Thigh, Brown, LF, 1 pc Cuff, Thigh, Brown, Infant, Black, LF, Infant, Orange, LF, 1 pc Cuff, Infant, Orange, Child, Black, LF, Child, Green, LF, 1 pc Cuff, Child, Green |
Features
- Clock-style gauge with a large, easy-to-read, 6” luminescent dial for high visibility in virtually any light condition
- Manometer angled back 15° for easy viewing
- Height-adjustable Spider-Leg™ caster stand with range of 34” to 48” (from bottom of base to top of unit); 18” base diameter
- Precision-crafted, 300mmHg Japanese engineered manometer with no-pin stop movement, withstands the heaviest use
- Adcuff inflation system includes nylon cuff, Adflow bulb and valve, and eight-foot length (when extended) coiled tubing
- Adflow filter screen check and deflation valve for reduced dust build-up
- Adflow chrome-plated brass air release valve with micro-threads for precise deflation control
- Complete with basket and all necessary hardware and assembly instructions (some assembly required)
- Lifetime calibration warranty
Specifications
| Sphyg Type: | Clock-Mobile |
| Gauge: | 805 |
| Gauge Warranty: | Lifetime |
| Sphyg Accuracy: | +/-3mmHg @ 50ºF(10ºC) – 104ºF(40ºC) |
| Sphyg Accuracy: at extended temperature range |
+/-3mmHg or 2% whichever is greater @ <50ºF(10ºC) and >104ºF(40ºC) |
| Storage Temp: | -4ºF (-20ºC) – 131ºF(55ºC) |
| Valve Type: | ADFLOW |
| Number of tubes: | 2 Tubes |
| Inflation Warranty: | 3 Year |
| Zipper / Storage case: | NA |
