Features

• Seven pre-configured workflow settings for simple set-up.
• Auto-snapshot of most critical alarms.
• Alarm reporting options for better alarm management and instant care in cases of arrhythmia, high/low blood pressure, and ECG-lead detachment.
• Convenient screen lock button for easy cleaning, maintenance, and intra-hospital transport.
• Capacitive touchscreen for fast response and enhanced user experience.
• Uninterrupted display of primary ECG-lead waveform and other vital signs across settings.
• Choice of numerical or continuous waveform monitoring.
• Large numeric mode that enables critical parameter visibility even up to four meters.

Specifications

• Weight: 25 lb (11.3 kg).
• Dimensions: 18″ x 18″ x 18″ (45.7 cm x 45.7 cm x 45.7 cm).
• Display:
  • Size: 12.1″ (diagonal).
  • Resolution: 1280 x 800 pixels (WVGA).
  • Number of Waveforms: Up to 6.
  • Display Layout and Colors: User-configurable.
  • Controls: Capacitive Touch Screen and Trim Knob control and hard keys (standard).
• ECG:
  • Leads Available:
    • 3-Lead Configuration: I, II, III.
    • 5-Lead Configuration: I, II, III, aVR, aVL, aVF, and V.
  • Sweep Speed: 12.5, 25, or 50 mm/s.
  • Gain Range: 0.5 x , 1 x, 2 x, and 4 x.
  • Heart Rate Accuracy: 30 to 300 bpm, +/- 5% or +/-5 bpm, whichever is greater.
  • 50/60 Hz Power Supply:
    • Monitor: 0.5 to 40 Hz.
    • ST: 0.05 to 40 Hz.
    • Diagnostic: 0.05 to 145 Hz.
  • Pacemaker Detection:
    • Range: 2 to 700 mV.
    • Pulse Width: 0.5 to 2 ms.
  • Arrhythmia Analysis: Asystole, V Fib / V Tach, V Tach, VT>2 R on T, V Brady, Couplet, Bigeminy, Accelerated Ventricular arrhythmia, Multifocal PVCs, A Fib, Missing beat, Pause, Tachy, Brady, Trigeminy.
  • ST Segment Analysis:
    • Numeric Range: -9 to +9 mm (-0.9 to +0.9 mV).
    • Accuracy: +/- 0.2 mm or +/- 10%, whichever is greater, within the measurement range of -8 to 8 mm.
    • Numeric Resolution: 0.1 mm (0.01 mV).
    • ST Trends: Up to 168h.
  • Range:
    • Adult/Pediatric: 4 to 120 resp/min.
    • Neonate: 4 to 180 resp/min.
  • Accuracy: +/- 5% or +/- 5 resp/min, whichever is greater.
  • Gain Range: 0.1 to 5 cm/Ohm.
• SpO₂:
  • GE:
    • Pulse Oximetry Measurement Range: 1 to 100%.
    • Pulse Rate: 30 to 250 bpm.
    • Saturation Measurement Accuracy:
      • Without Motion-Adult/Pediatric Finger Sensor: 70 to 100% +/- 2%
      • Without Motion-Neonate: 70 to 100% +/- 3%.
      • With Motion-Adult/Pediatric/Neonate: 70 to 100% +/- 3%.
      • Low Perfusion-Adult/Pediatric: 70 to 100% +/-3% (1~69% unspecified).
    • Pulse Rate: Without Motion: +/- 2 bpm (adult/pediatric/neonatal).
  • Nellcor:
    • Pulse Oximetry Measurement Range: 1 to 100%.
    • Pulse Rate: 20 to 250 bpm.
    • Saturation Measurement Accuracy:
      • Adult: 70 to 100% +/- 2%.
      • Neo: 70 to 100% +/- 3%.
      • Low Perfusion: 70 to 100% +/- 2%; 0~69% unspecified.
    • Pulse Rate: +/- 3 bpm.
  • Masimo:
    • Pulse Oximetry Measurement Range: 1 to 100%.
    • Pulse Rate: 25 to 240 bpm.
    • Saturation Measurement Accuracy:
      • Without Motion-Adult/Pediatric: 70 to 100% +/- 2%.
      • Without Motion-Neonate: 70 to 100% +/- 3%.
      • With Motion-Adult/Pediatric/Neonate: 70 to 100% +/- 3%.
      • Low Perfusion: 70 to 100% +/-2% (0 to 69% unspecified).
    • Pulse Rate:
      • Without Motion: +/- bpm.
      • With Motion: +/- 5 bpm.
• NIBP:
  • Measurement Technique: Oscillometric with step deflation.
  • Modes: Manual, Automatic, Stat.
  • Systolic Measurement Range:
    • Adult/Pediatric: 30 to 290 mmHg.
    • Neonate: 30 to 260 mmHg.
  • MAP Measurement Range:
    • Adult/Pediatric: 20 to 260 mmHg.
    • Neonate: 20 to 125 mmHg.
  • Diastolic Measurement Range:
    • Adult/Pediatric: 10 to 220 mmHg.
    • Neonate: 10 to 110 mmHg.
  • Accuracy: Meets AAMI ISO81060-2 and IEC 80601-2-30.
  • Default Initial Inflation Pressure:
    • Adult/Pediatric: 135 +/- 15 mmHg.
    • Neonate: 100 +/- 15 mmHg.
  • Maximum Determination Time:
    • Adult/Pediatric: 2 min.
    • Neonate: 100 +/- 15 mmHg.
  • Over Pressure Monitor:
    • Adult/Pediatric: 294 +/-6 to 330 mmHg.
    • Neonate: 147 +/- 3 to 165 mmHg.
• Invasive Blood Pressure:
  • Measurement Range: -40 to 320 mmHg (15.3 to 42.7 kPa).
  • Measurement Accuracy; +/- 5% or +/- 2 mmHg, whichever is greater.
  • Frequency Response: 4 to 22 Hz.
  • Transducer Sensitivity: 5 μV/V/mmHg.
• Temperature:
  • Numerical Display: T1, T2, T2-T1.
  • Measurement Range: 10 to 45 degrees C (50 to 113 degrees F).
  • Measurement Accuracy: +/- 0.1 degrees C without probe.
  • Display Resolution: 0.1 degrees C.
  • Probe: YSI probes recommended by GE Healthcare.
• Networking:
  • Compatibility: CARESCAPE Network.
  • Wi-Fi Connectivity: IEEE 802.11a/b/g/n.
  • Wi-Fi Security:
    • WPA-Personal.
    • WPA2-Personal.
    • WPA-Enterprise.
    • WPA2-Enterprise.
